GJFJH Distribution Cable

5 0 Reviews
Indoor Cable, LSZH Aramid Yarn Strength
Installation: Indoor, Inner electric cable tube.
Applications: For direct connector assembly, Indoor any purpose cable distribution, Backbone distribution cable in building.
Price: $ 75.5  -  312 / KM
Fiber No.:
Quantity:
  • GJFJH
  • Headway

Indoor Communication Cable(GJFJH)


Cable Design


GJFJH(改)


Technical data

No. of cable

4

6

8

12

24

Fiber Model

G652D

Tight lines

Material

PVC

Thickness±0.03mm

0.32

Diameter±0.06mm

0.9

Strength Member

Material

Aramid Yarn

Outer Sheath

Material

LSZH

Thickness±0.2mm

0.55

0.65

0.8

0.9

1.0

Colour

Yellow/Black

Cable   Diameter±0.2mm

5.0

5.5

5.8

6.2

8.5

Cable Weight±5kg/km

17

21

28

36

60

Max Attenuation

1310nm

dB/km

0.36

1550nm

0.22

Allowable Tensile Strength

Short Term

N

440

Long Term

200

Allowable Crush Resistance

Short Term

N/100mm

1000

Long Term

200

Min.bending radius

Without Tension

10.0×Cable-φ

Under Maximum Tension

20.0×Cable-φ

Temperature range

Installation

-20~+60

Transport&Storage

-40~+70

Operation

-40~+70
