GYFXTY Non-armored Outdoor Cable G652D
Cable Design
Technical Data
No. of cable | 2～6 | 8～12 | |
Fiber Model | G.652D | ||
Loose Tube | Material | PBT | |
Diameter | 2.0±0.06 mm | 2.2±0.06 mm | |
Thickness | 0.30±0.03 mm | ||
Colour | Nature | ||
Strength Member | Material | FRP | |
Diameter | 0.5±0.05 mm | 0.8±0.05 mm | |
Outer Sheath | Material | HDPE | |
Thickness | 1.6±0.1 mm | 2.0±0.1 mm | |
Cable Diameter | 5.2±0.2 mm | 6.2±0.2 mm | |
Cable Weight | 21.0±2.0 kg/km | 31.0±2.0 kg/km | |
Cable length | 2000+3.0m | ||
Min. bending radius | Without Tension | 10.0×Cable-φ | |
Under Maximum Tension | 20.0×Cable-φ | ||
Temperature range （℃） | Installation | -20~+60 | |
Transport & Storage | -40~+70 | ||
Operation | -40~+70 | ||
GYFXTY Non-armored Outdoor Cable G652D
Cable Design
Technical Data
No. of cable | 2～6 | 8～12 | |
Fiber Model | G.652D | ||
Loose Tube | Material | PBT | |
Diameter | 2.0±0.06 mm | 2.2±0.06 mm | |
Thickness | 0.30±0.03 mm | ||
Colour | Nature | ||
Strength Member | Material | FRP | |
Diameter | 0.5±0.05 mm | 0.8±0.05 mm | |
Outer Sheath | Material | HDPE | |
Thickness | 1.6±0.1 mm | 2.0±0.1 mm | |
Cable Diameter | 5.2±0.2 mm | 6.2±0.2 mm | |
Cable Weight | 21.0±2.0 kg/km | 31.0±2.0 kg/km | |
Cable length | 2000+3.0m | ||
Min. bending radius | Without Tension | 10.0×Cable-φ | |
Under Maximum Tension | 20.0×Cable-φ | ||
Temperature range （℃） | Installation | -20~+60 | |
Transport & Storage | -40~+70 | ||
Operation | -40~+70 | ||
