LAN Cable CAT5e UTP

5 0 Reviews

Price: $ 48.5 / 305m/Box
Quantity:

Annealed Solid Bare Copper

HDPE  insulation

PVC Jacket



Reference Standard : TIA/EIA-568-C.2, ISO/IEC11801,

Working Temperature Range-20℃~70℃

Min. Installation Temperature0℃


                            Construction
                        Electrical characteristic(20℃)
 Conductor                                        1.Conductor DC Resistance≤95Ω/km
 Material Annealed  Bare Copper 2.Resistance Unbalance :Within a Pair: ≤2% @20℃
 Nominal diameter(mm)0.50±0.005 mm Between Pairs: ≤4% @20℃
 Insulation 3 Insulation  Resistance≥5000MΩ.km
 Material HDPE 4.Mutual capacitance      (1kHz)≤56nF/km
Nom/Min Thickness(mm)0.19/0.17 Others see table 1 and table 2
 Insulation Diameter(mm)0.89±0.05  Physical Properties
 Twisted pair 1. Insulation tensile strength≥ 16.5MPa
Pair NoInsulation Color Codes 2. Insulation elongation≥ 300%
  1.White/Blue(Strip)         Blue  Aging condition100℃±2℃,48h
  2.White/Orange(Strip)     Orange 3. Aged Insulation tensile strength≥75% of Unaged
  3.White/Green(Strip)      Green 4. Aged Insulation elongation≥75% of Unaged
  4.White/Brown(Strip)     Brown 5. Jacket tensile strength≥13.5MPa
  Pair Twist Lay Length               ≤ 25mm 6. Jacket elongation≥ 150%
Cabling  Aging condition100℃±2℃,168h
Stranding construction1*4 7. Aged Jacket tensile strength≥12.5MPa
Jacket 8. Aged Jacket elongation ≥ 125%
 Material PVC 9.Environment RequirementsMeet the standard of RoHS
Color:Gray
Thickness:0.52±0.05mm
Jacket Diameter(mm): 5.0±0.2
Rip Cord:630D
