MPO/MTP Cassette

5 0 Reviews
Data Centre Infrastructure.
High Density Fiber Management.
Telecommunications networks and Broadbank/CATV networks.
LAN/WAN premises
Price: $ 17.5  -  36.5 / PCS
Type:
Fiber Type:
Quantity:
  • MPO/MTP Cassette
  • Headway


Features

High-density and small desing, Easy and fast installation

Available in 12/24/48 fiber versions.

Field connections with guaranteed quality and simplifies fiber routing.

Modular system management, easy reconfiguration for moves, adds and changes.

Customized fiber polarity in the module.


Connector Performance

Connector MatingIL AverageIL MaxReturn LossConnector MatingIL Average IL MaxReture Loss
MTP/MPO(MM)0.20dB0.60dBNAMTP/MPO(SM)0.25dB0.75dB>60dB
LC,SC(MM)0.15dB0.30dBNALC,SC(SM)0.18dB0.30dB>55/60dB*UPC/APC



Technical Specification

ElementCharacteristic
FibreOS1/OS2, OM1, OM2, OM3,OM4
Adaptors-MTP/MPO;                        -LC Duplex; LC Quadruple; SC Duplex
Connectors-MTP/MPO connector;   - LC connector; SC connector
Cassette MaterialColled rolled steel
Operating Temperature-20~+60 ℃
Storage Temperature-40~+70 ℃
Dimensions34x109x133mm
