GJFJH
Headway
Indoor Communication Cable(GJFJH)
Cable Design
Technical Data
No. of cable | 48 | ||
Fiber Model | G.652D | ||
Tight lines | Material | PVC | |
Thickness（±0.03）mm | 0.32 | ||
Diameter（±0.06）mm | 0.9 | ||
Center Strength Member | Material | FRP+PE | |
Diameter（±0.1）mm | 2.5 | ||
Strength Member | Material | Aramid Yarn | |
Inner Sheath | Material | LSZH | |
Thickness（±0.1）mm | 0.6 | ||
Colour | Yellow | ||
Outer Sheath | Material | LSZH | |
Thickness（±0.2）mm | 1.4 | ||
Colour | Yellow | ||
Cable Diameter（±0.5）mm | 16.5 | ||
Cable Weight（±10）kg/km | 230 | ||
Max Attenuation | 1310nm | dB/km | 0.8 |
1550nm | 0.6 | ||
Allowable Tensile Strength | Short Term | N | 1320 |
Long Term | 400 | ||
Allowable Crush Resistance | Short Term | N/100mm | 1000 |
Long Term | 300 | ||
Min. bending radius | Without Tension | 10.0×Cable-φ | |
Under Maximum Tension | 20.0×Cable-φ | ||
Temperature range （℃） | Installation | -20~+60 | |
Transport&Storage | -40~+70 | ||
Operation | -40~+70 | ||
